Smart Agriculture Solution – Georgia

Smart Agriculture Solution – Georgia

Soil Nutrient Data Is Central In Agriculture Or The Farming Process. Are You Interested In Automating Your Farming Process?

If The Answer Is YES, You Need Our Smart Agriculture IoT Solution Called

PANDORA GEORGIA

Smart Agriculture Solution – Georgia

Smart Agriculture IoT Solution

IoT Solution for Real-Time Monitoring

Pandora Georgia is the smart solution to problems related to agriculture, aquaculture, environmental preservation and surveillance. It allows you to monitor the quality of soil, i.e. its temperature, pH level, humidity and potassium, phosphorus and nitrogen values. It is a water resistant wireless device with GSM connectivity, and is battery-powered with solar charging. It is equipped with interchangeable sensor probes which are inserted into the soil to capture data automatically and in real time. The data is displayed on the Pandora dashboard for analysis and generating reports. It is also recorded in the cloud and can be easily accessed and downloaded.

This device helps reduce manpower, wastage of time and natural resources, allowing you to get accurate readings from any area of your farm, no matter how large the area or when power supply is not available, or even during bad weather.

Capabilities

- It measures pH value, water level and soil nutrients value (NPK)
- It consists of two probes that pass through the soil, measuring the resistance value to determine the value
- It is made of a corrosion-resistant material, giving it a long service life
- It is equipped with wireless technology with GSM connectivity and is solar powered

Smart Agriculture IoT Solution

IoT Solution for Real-Time Monitoring

Pandora Georgia is the smart agriculture iot solution to problems related to agriculture, aquaculture, environmental preservation and surveillance. It allows you to monitor the quality of soil, i.e. its temperature, pH level, humidity and potassium, phosphorus and nitrogen values. It is a water resistant wireless device with GSM connectivity, and is battery-powered with solar charging. It is equipped with interchangeable sensor probes which are inserted into the soil to capture data automatically and in real time. The data is displayed on the Pandora dashboard for analysis and generating reports. It is also recorded in the cloud and can be easily accessed and downloaded.

This device helps reduce manpower, wastage of time and natural resources, allowing you to get accurate readings from any area of your farm, no matter how large the area or when power supply is not available, or even during bad weather.

Capabilities

- It measures pH value, water level and soil nutrients value (NPK)
- It consists of two probes that pass through the soil, measuring the resistance value to determine the value
- It is made of a corrosion-resistant material, giving it a long service life
- It is equipped with wireless technology with GSM connectivity and is solar powered

Check out the video to understand our Smart Agriculture IoT Solution

Product Spectification

Technical Data

– Multi wireless network supports (GSM, 4G, WIFI, Sigfox, Lora, NBIoT)
– Support up to 3 – RS485 sensors or control modules
– Allow for solar charge or direct power (19v)
– Built-in temperature and humidity sensors for device status monitoring
– Built-in voltage and current sensors for solar & battery status monitoring
Display Refresh Time 10 minutes/30 minutes/1 hour/1 day (customizable)
Battery Life Up to 1 month

Pandora GEORGIA product sketch

GeorgiaSketch

Common Data

Battery Type

18650 Lithium Battery * 3 in series

Weight

570 g ( battery included )

Dimensions

Length x Width x Height : 200mm x 155mm x 80mm

Material / Housing

ABS , IP54 Rating

Data Logger

>50,000 measuring values

Software

PANDORA

Soil Moisture/ Soil pH/ Soil NPK/ Soil Temperature Sensor

Measuring Range
Moisture 0 ~ 100% Precision Range ±3% ( 0 ~ 53% ) ±5% ( 53 ~ 100% )
pH 3-9pH Precision Range ±0.3pH
NPK 0-1999mg/kg Precision Range ±2%F.s
Operating Range -20°C – 60°C

Input Voltage

12V

Protection Level

IP68

Response Time

<1s
